LSAT
LSAT is a kind of twin free perovskite crystal, which is well matched with high-temperature superconductors and various oxide materials. Its low cost is expected to replace LaAlO3 and SrTiO3 as epitaxial oxide thin film single crystal substrates, which are widely used in giant magnetoelectric and superconducting devices.
| Performance and parameters | |
| Growth method | Czochralski method |
| Crystal Structure | cubic |
| Lattice Constant | a=3.686 Å |
| Color and appearance | From colorless to light brown, no twins and visible domains according to annealing |
| Density | 6.74 g/cm3 |
| Melting Point | 1840℃ |
| Mohs Hardness | 6.5mohs |
| Crystallographic Orientation | <100>、<110>、<111> |
| Redirection Precision | ±0.5° |
| Redirection the edge | ±1° |
| Size (special size can be customized according to customer needs) | 10×10x0.5mm、10×5x0.5mm、5×5x0.5mm、15×15x0.5mm |
| Polishing | Single or double side |
| Surface Roughness | ＜5 Å |
| Packing | Class 1000 super clean room Class 100 super clean bag or single chip crystal box package |
